Hydrogen Industrial Piston Compressor

Motor Power: 7.5 – 65 kw
Discharged Pressure: 0.1 – 1.2 MPa
Air Delivery: 0.6 – 12.5 m3/min

Get Quote to become an agent. Learn more about agency policy.
More competitive agent price by FCL!

Hydrogen series piston compressor is a product specially designed and developed for special gas media on the basis of our company’s leading product oil-free lubricating air compressor, in addition to the general oil-free lubricating air.
In addition to the characteristics of the air compressor, it has been specially designed for the particularity of the compressed medium. The model has a compact structure, small size, beautiful appearance, stable operation, low specific power, and low noise.
The main features are as follows:
1. Absolutely sealed, the compressed medium does not leak, ensuring environmental production safety.
2. Using oil-free lubrication, the compressed medium does not contain oil, does not react, and maintains the original gas characteristics.
3. Equipped with gas recovery device to avoid gas loss.

Application:

On-site:

hydrogen industrial piston compressor customer site

Hydrogen Piston Compressor Technical Parameter
Model		EZW-0.6/0.1-8	EZW-0.9/7	EZW-1.5/7	EZW-10/8	EZW-12.5/1	EZW-2.5/7
Type		Vertical single cylinder single acting	Vertical single cylinder double acting		Double cylinder double acting		Double cylinder single acting
Medium		Hydrogen
Stage		1	1	1	2	1	2
Suction Pressure	MPa	0.1	0.11	0.04	0.005	0.1	0.11
Discharged pressure	MPa	0.8	0.7	0.7	0.8	0.1	0.7
Capacity	m³/min	0.6	0.9	1.5	10	12.5	2.5
Speed	r/min	730	450	730	740	740	660
Shaft Power	kW	≤7.3	≤11	≤12.3	≤57	≤36	≤19
Cylinder dia	mm	φ150	φ150	φ160	φ285/φ175	φ285/φ175	φ250/φ150
Stroke	mm	100	100	100	140	140	110
Suction temp	℃	≤40	≤40	≤40	≤40/45	≤40/45	≤35/45
Discharged temp	℃	≤180	≤180	≤180	≤160	≤160	≤160
Temp.at outlet of cooler	℃	≤40	≤40	≤40	≤40	≤40	≤40
Oil temp	℃	≤70	≤70	≤70	≤70	≤70	≤70
Cooling		Water cooling
Lubricating		Splash lubrication				Oil pump lubricates crankshaft, connecting rod, crosshead
Driving		Belt drive				Flexible coupling direct coupling	Belt drive
Max.temp.of intlet water	℃	≤30	≤30	≤30	≤30	≤30	≤30
Max.temp.of outlet water	℃	≤40	≤40	≤40	≤40	≤40	≤40
Cooling water consumption	m³/h	0.72	0.45	0.72	2.4	2	1.5
Motor Type		YB132M-4	Y160M-4	YB160L-4	Y280M2-8	YB280M-8	YB200L1-6
Motor speed	r/min	1440	1463	970	740	740	970
Motor power	kW	7.5	11	18.5	65	37	22
Noise	dB(A)	≤103	≤80	≤103	≤104	≤104	≤103
Weight	kg	776	776	850	2986	2860	1600
Dimensions (L×W×H)	mm	1662×648×1530		1662×663×1531	1880×1460×2030		2007×1640×1668
